| Model | RD18000KSE | RD18000KSE-3 |
| Rated Frequency (HZ) | 50 | 50 |
| Rated Output Powewr (KW) | 16 | 15 |
| Max Power (KW) | 15 | 14.5 |
| Rated Voltage (V) | 220 | 220/380 |
| Power Fac | Single1 (lag) | Three 0.8 (lag) |
| Insulation | F | |
| Pole No. | 2 | |
| Exciting Way / Panel Type | Brush, exciting-self voltage-constant (with AVR) T: General panel / TA: Intelligent panel | |
| Output Socket | Single-phase socket, wiring terminal singlephase socket, Three-phase socket | |
| DC12V Output | 12V, 8.3A | |
| Dimensions(mm) | 1270*680*795 | |
| Net Weight (KG) | 272 | |
| Noise (7m) dB | 78 | |
| Structure Type | Fully-Closed | |
| Engine Model | R2V95 | |
| Engin Type | V-twin, two-cylinder, four-stroke | |
| Cylinder NO.-Bore*Stroke(mm) | 95*88 | |
| Total Displacement (L) | 1.247 | |
| Compressed Ratio | 20:01 | |
| cooling way | Air-cooled | |
| Lubricating Way | Pressure & Splashing | |
| Starting Way | Electric | |
| Fuel Used | 0 # (summer) -10 # ( winter) -35 # (cold winter) light diesel | |
| Oil Used | SAE10W30 (CD 级以上 ) SAE10W30 (CD grade above) | |
| Lubricating Oil Capacity (L) | 2.7 | |
| Starting Motor Capacity(V-KW) | 12V 1.4KW | |
| Dynamo Capacity (V-A) | 12V 8.3A | |
| Battery Capacity(V-AH) | 12V 45AH | |
